| Product Name | Status | Description | Features | Package | Q-Level |
| Si4386DY | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.007Ω@10V; RDS(on)=0.0095Ω@4.5V; Qg=11nC | SMD SO-8 | ||
| Si4634DY | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.0052Ω@10V; RDS(on)=0.0067Ω@4.5V; Qg=21.5nC | SMD SO-8 | ||
| Si4660DY | N-Channel 25-V (D-S) MOSFET | RDS(on)=0.0058Ω@10V; RDS(on)=0.007Ω@4.5V; Qg=17nC | SMD SO-8 | ||
| Si7110DN | N-Channel 20-V (D-S) MOSFET | RDS(on)=0.0053Ω@10V; RDS(on)=0.078Ω@4.5V; Qg=14nC | SMD PowerPAK 1212-8 | ||
| Si7114DN | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.0075Ω@10V; RDS(on)=0.010Ω@4.5V; Qg=12.5nC | SMD PowerPAK 1212-8 | ||
| Si7686DP | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.0095Ω@10V; RDS(on)=0.014Ω@4.5V; Qg=9.2nC | SMD PowerPAK SO-8 | ||
| Si7804DN | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.0185Ω@10V; RDS(on)=0.030Ω@4.5V; Qg=8.7nC | SMD PowerPAK 1212-8 | ||
| SiE822DF | N-Channel 20-V (D-S) MOSFET | RDS(on)=0.0034Ω@10V; RDS(on)=0.0055Ω@4.5V; Qg=24nC | SMD PolarPAK | ||
| SiE844DF | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.007Ω@10V; RDS(on)=0.010Ω@4.5V; Qg=13.1nC | SMD PolarPAK | ||
| SiR402DP | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.006Ω@10V; RDS(on)=0.008Ω@4.5V; Qg=14nC | SMD PowerPAK SO-8 | ||
| SiR462DP | N-Channel 30-V (D-S) MOSFET | RDS(on)=0.0079Ω@10V; RDS(on)=0.0095Ω@4.5V; Qg=8.8nC | SMD PowerPAK SO-8 | ||
| SiR892DP | N-Channel 25-V (D-S) MOSFET | RDS(on)=0.0032Ω@10V; RDS(on)=0.0042Ω@4.5V; Qg=20nC | SMD PowerPAK SO-8 |
